The lug lid and lock ring lid can be perfectly match with the conical pail with the larger top while smaller bottom, which provides an effective solution for the pail products transportation.
With our patented technology, we have made a precision sealing for all pails.

OEM:The color, size, finish and sealing can all be customized

Use:5Liter -35liter metal bucket/paint bucket


Product Information
Capacity: 5 Liter - 35 Liter
Diameter: 193mm - 380mm
Height: Adjustable
Material: Tinplate
Thickness: 0.28mm - 0.55mm
Lid Style: Standard Lug lid,Deep drawing type lid
Certificate: ISO 9001
Design: Accept Customization
UN approved: UN IA1009
Coating: Lacquer, Antirust Oil, Epoxy Resin
Printing: CMYK And Pantone
(Cooperate with China's top printing factory to restore color)
Applications: Paint
Adhesives
Liquid Waterproofing Membranes
chemical industry
Other Building Products
Product Specification

Capacity

for pail

Inside

Diameter

Outside

 Diameter

Edge concav

e height

Edge convex

height

Depth

Eva

 sealing ring

5 Liter/6liter 193mm 195mm 11mm 25mm 7.5mm

Thinckness-5.5mm

Width 8.8mm

10 Liter 245mm 247mm 11mm 25mm 7.5mm

Thinckness-5.5mm

Width 8.8mm

15 Liter/18 Liter/20 Liter/25Liter 297mm 300.5mm 11mm 26mm 8mm

Thinckness-5.5mm

Width 8.8mm

35 Liter 325mm 326mm 11mm 26mm 8mm

Thinckness-5.5mm

Width 8.8mm

50 Liter 380mm 382mm 11mm 26mm 8mm

Thinckness-5.5mm

Width 8.8mm
